MIL-DTL-55181/6D
NOTES:
1. Dimensions are in inches.
2. Metric equivalents are given for information only.
3. Unless otherwise specified tolerances are ±.005 inch (0.13 mm) for three place decimals and
±.01 inch (0.3 mm) for two place decimals.
4. Material: Carbon steel, cadmium plated in accordance with SAE-AMS-2700.
5. The number of teeth shall be at the option of the manufacturer.
FIGURE 2. Grounding washer Continued.
REQUIREMENTS:
Dimensions and configurations: See figures 1 and 2, and table I.
Contacts: 7.5 ampere current rating, 12 AWG.
Mating Connector: M55181/5-01, M55181/5-02, M55181/5-03, and M55181/5-04.
Part or Identifying Number (PIN): See table I.
Supersession, cross-reference and mating connectors: See table II.
TABLE I. PIN.
PIN
M55181/6-01
Without grounding washer
M55181/6-01W
With grounding washer
TABLE II. Supersession and cross reference data.
Old type designator 1/
1/
PIN
Mating type designator
MW10M(M)B11
MW20F(M)B00
M55181/6-01
MW10M(M)B13
MW20F(M)B00
M55181/6-01
MW10M(M)B17
MW20F(M)B00
M55181/6-01
MW10M(M)B19
MW20F(M)B00
M55181/6-01
MW10M(M)B15
MW20F(M)B00
M55181/6-01
1/ This type designator shall not be referenced for procurement purposes.
4
