MIL-DTL-55181/7D
Inches
mm
Inches
mm
Inches
mm
Inches
mm
.029
0.74
.089
2.26
.313
7.95
.618
15.70
.038
0.96
.090
2.29
.314
7.98
.620
15.75
.039
0.99
.094
2.39
.344
8.74
.625
15.87
.040
1.01
.099
2.51
.374
9.50
.703
17.85
.041
1.04
.100
2.54
.375
9.52
.737
18.72
.042
1.07
.125
3.17
.380
9.65
.748
19.00
.045
1.14
.130
3.30
.406
10.31
.925
23.49
.047
1.19
.138
3.50
.422
10.72
.995
25.27
.048
1.22
.150
3.81
.456
11.58
1.000
25.40
.050
1.27
.155
3.94
.504
12.80
1.095
27.81
.052
1.32
.166
4.21
.513
13.03
1.103
28.01
.061
1.55
.220
5.59
.519
13.18
1.470
37.34
.072
1.83
.233
5.92
.528
13.41
1.585
40.26
.076
1.93
.241
6.12
.564
14.32
2.125
53.97
.080
2.03
.244
6.20
.570
14.48
2.500
63.50
.082
2.08
.260
6.60
.582
14.78
.084
2.13
.292
7.42
.610
15.49
NOTES:
1. Dimensions are in inches.
2. Metric equivalents are given for information only.
3. Unless otherwise specified tolerances are ±.005 inch (0.13 mm) for three place decimals and
±.01 inch (0.3 mm) for two place decimals.
4. Angular tolerances shall be ±30 minutes unless otherwise specified.
5. See table I for cable size accommodations.
FIGURE 1. Dimensions and configuration - Continued.
REQUIREMENTS:
Dimensions and configuration: See figure 1 and table I.
Contacts: 7.5 ampere current rating, 20 AWG.
Mating Connector: M55181/8-01.
Part or Identifying Number (PIN): M55181/7 - (dash number specified in table I).
TABLE I. Dash numbers, cross reference and intermating table.
Cable size accommodation
Mating connector
1/
PIN
Type designator
Type designator 1/
MIN
MAX
PIN
M55181/7-01
MW10M(M)D11
.292 (7.42)
.343 (8.71)
M55181/8-01
MW20F(M)D00
M55181/7-02
MW10M(M)D13
.323 (8.20)
.406 (10.31)
M55181/8-01
MW20F(M)D00
M55181/7-03
MW10M(M)D17
.448 (11.38)
.531 (13.48)
M55181/8-01
MW20F(M)D00
M55181/7-04
MW10M(M)D19
.511 (12.98)
.593 (15.06)
M55181/8-01
MW20F(M)D00
M55181/7-05
MW10M(M)D15
.386 (9.80)
.468 (11.88)
M55181/8-01
MW20F(M)D00
1/ This type designator shall not be referenced for procurement purposes.
