MIL-DTL-55302/111B
TABLE I. Dash numbers and dimensions for types II and III.
A
B
C
D
Number
Dash
of
Basic
Ref.
Ref
numbers
contacts
01
13
.800 ±.005
.600
.300
.400
02
25
1.200 ±.005
1.000
.700
.800
03
37
1.600 ±.005
1.400
1.100
1.200
04
49
2.000 ±.005
1.800
1.500
1.600
05
61
2.400 ±.005
2.200
1.900
2.000
Inches
mm
Inches
mm
Inches
mm
Inches
mm
Inches
mm
.004
0.10
.050
1.27
.136
3.45
.300
7.62
1.200
30.48
.005
0.13
.055
1.40
.150
3.81
.345
8.76
1.400
35.56
.007
0.18
.065
1.65
.154
3.92
.355
9.02
1.500
38.10
.008
0.20
.070
1.78
.170
4.32
.400
10.16
1.600
40.64
.013
0.33
.071
1.80
.175
4.45
.600
15.24
1.800
45.72
.026
0.66
.079
2.01
.180
4.57
.700
17.78
1.900
48.26
.028
0.71
.084
2.13
.200
5.08
.800
20.32
2.000
50.80
.039
0.99
.100
2.54
.255
6.48
1.000
25.40
2.200
55.88
.044
1.12
.120
3.05
.265
6.73
1.100
27.94
2.400
69.96
NOTES:
1. Dimensions are in inches.
2. Metric equivalents are given for information only.
3. Unless otherwise specified, tolerances are ±.005 (0.13 mm) on three place decimals and ±2° on
angles.
4. These connectors mate with connectors specified in MIL-DTL-55302/7, and are primarily for use with
multilayered printed wiring boards.
5. Positional tolerances of guide pins shall apply at datum plane X.
6. Pad(s) suitable for printed circuit board support are required. Dimensions and location(s) are optional.
FIGURE 1. Connectors, receptacle, .100 (2.54 mm) spacing - Continued.
