MIL-DTL-55302/125D
Inches
mm
Inches
mm
Inches
mm
Inches
mm
.002
0.05
.038
0.97
.132
3.35
.900
22.86
.003
0.08
.040
1.02
.140
3.56
.950
24.13
.005
0.13
.047
1.19
.150
3.81
1.000
25.40
.006
0.15
.050
1.27
.155
3.94
1.050
26.67
.008
0.20
.057
1.45
.280
7.11
1.195
30.35
.009
0.23
.060
1.52
.285
7.24
2.000
50.80
.010
0.25
.090
2.29
.300
7.62
2.290
58.17
.016
0.41
.093
2.36
.325
8.26
2.470
62.74
.018
0.46
.100
2.54
.340
8.64
.025
0.64
.105
2.67
.750
19.05
NOTES:
1. Dimensions are in inches.
2. Metric equivalents are given for general information only.
3. Unless otherwise specified, tolerance is ± .005 (0.13 mm) and ± 2° on angles.
4. These connectors mate with connectors specified in MIL-DTL-55302/126.
5. Dimension applies at point of egress from spacer block.
FIGURE 1. Connectors, plug, .050 (1.27 mm) spacing Continued.
2
