MIL-DTL-55302/131D
Part or Identifying
Number of
Type of
Number (PIN)
contacts
termination
M55302/131-01
96
Printed circuit tails
M55302/131-02
64
Printed circuit tails
NOTE: PIN 02 connectors have the middle row (row B)
of contacts excluded.
Inches
mm
Inches
mm
Inches
mm
Inches
mm
.001
0.03
.024
0.61
.102
2.59
.343
8.71
.002
0.05
.025
0.64
.104
2.64
.433
11.00
.004
0.10
.027
0.69
.110
2.79
.500
12.70
.005
0.13
.035
0.89
.127
3.23
.735
18.67
.008
0.20
.039
0.99
.146
3.71
3.100
78.74
.010
0.25
.040
1.02
.189
4.80
3.354
85.19
.015
0.38
.047
1.19
.200
5.08
3.500
88.90
.017
0.43
.070
1.78
.209
5.31
3.700
93.98
.020
0.51
.098
2.49
.236
5.99
.022
0.56
.100
2.54
.252
6.40
NOTES:
1. Dimensions are in inches.
2. Metric equivalents are given for information only.
3. Unless otherwise specified, tolerance is ± .010 (0.25 mm).
4. These connectors mate with connectors specified in MIL-DTL-55302/132.
FIGURE 1. Connector, plug, .100 (2.54 mm) spacing Continued.
