MIL-DTL-55302/139C
Example of PIN:
M55302/139
A
160
X
Basic number of specification sheet
Type of terminal (see figure 1)
A
=
Solder cup
B
=
Dip terminal .109 inch (2.77 mm) length
C
=
Dip terminal .140 inch (3.56 mm) length
D
=
Wrappost
E
=
Dip terminal .172 inch (4.37 mm) length
F
=
058 flexible circuit terminal
H
=
100 flexible circuit terminal
Number of contacts (see figure 1)
Type guide pin and/or socket
X
=
Full round
Y
=
D-shaped
F
=
Fixed jackset
S
=
200 slotted turning jackset
H
=
200 hex turning jackset
Marginal notations are not used in this revision to identify changes with respect to the previous issue due to the extent
of the changes.
In addition to MIL-DTL-55302, this document references the following:
MIL-DTL-55302/57
MIL-DTL-55302/138
ASTM A581
ASTM A582
ASTM B196
ASTM B197
ASTM B488
SAE-AMS-QQ-N-290
SAE-AMS-QQ-P-35
CONCLUDING MATERIAL
Custodians:
Preparing activity:
Air Force - 11
DLA - CC
DLA - CC
(Project 5935-4552-000)
Review activities:
Air Force - 19, 99
NOTE: The activities listed above were interested in this document as of the date of this document. Since
organizations and responsibilities can change, you should verify the currency of the information above using the
ASSIST Online database at https://www.dodssp.daps.mil.
7
