MIL-DTL-55302/141C
Inches
mm
Inches
mm
Number of
72
84
96
.004
0.10
.375
9.53
Contacts
.005
0.13
1.93
49.02
W
1.93
2.23
2.53
.079
2.01
2.10
53.34
min
.106
2.69
2.23
56.64
X
2.10
2.40
2.70
.116
2.95
2.40
60.96
.118
3.00
2.53
64.26
.126
3.20
2.70
68.58
.202
5.13
NOTES:
1. Dimensions are in inches.
2. Metric equivalents are given for information only.
3. Unless otherwise specified, tolerance is ± .005 (0.13 mm).
4. Floating mount panel thickness .085 (2.15 mm) maximum.
FIGURE 5. Recommended panel cutouts - Continued.
REQUIREMENTS:
Dimensions and configurations: See figures 1 through 5.
Contact identification: See figure 3.
Contact retention: 4 pounds minimum for each contact.
Contact engagement: 0.7 ounce minimum, 3.6 ounces maximum.
Contact separation: 0.7 ounce minimum, 3.6 ounces maximum.
Contact resistance: The contact resistance shall not exceed 12 milliohms.
Dielectric withstanding voltage:
Sea level: 1,000 V rms, 60 Hz.
High altitude: 300 V rms, 60 Hz.
Current rating, maximum: 3.0 amperes at 25°C.
Keying pin: Two hexagonal keyed guides provide 36 polarizing positions. Keys are constructed in
accordance with M55302/154. Connectors are supplied with hex pins in the "1" and "A" positions,
except for 1/4-turn locking styles, which are keyed in "F" and "6" positions. When required, connectors
can be easily keyed to the desired position by using a standard wrench or screwdriver.
