MIL-DTL-55302/146C

Inches

.020

0.51

.138

3.51

.03

0.8

.139

3.53

.063

1.60

.155

3.94

.071

1.80

.157

3.99

.076

1.93

.158

4.01

.079

2.01

.177

4.50

.094

2.39

.185

4.70

.095

2.41

.271

6.88

.100

2.54

.303

7.70

.110

2.79

.317

8.05

.122

3.10

.374

9.50

.126

3.20

NOTES:

1. Dimensions are in inches.

2. Metric equivalents are given for information only.

3. Unless otherwise specified, tolerance is � .005 (0.13 mm).

FIGURE 3. Coaxial configurations � Continued.
