MIL-DTL-55302/153C
Part or Identifying Number (PIN): Consists of the letter M, the basic number of the specification sheet,
and a dash number compiled as follows:
Example:
*
*
*
2
*
M55302/153
Specification sheet number
Receptacle with pin contacts
Contact arrangement
(see figure 4)
Contact type 3 amperes
(see figure 4)
O Not applicable
Contact configuration coaxial/power (see figure 3)
X less coaxial and power contact
Indexing type
2 square post (16 positions)
1 hex post (36 positions)
Mounting hardware
(see MIL-DTL-55302/154)
Marginal notations are not used in this revision to identify changes with respect to the previous issue due
to the extent of the changes.
Referenced documents. In addition to MIL-DTL-55302, this document references the following:
MIL-DTL-55302/142
MIL-DTL-55302/154
MIL-DTL-55302/148
MIL-DTL-55302/155
MIL-DTL-55302/149
12
