MIL-DTL-55302/171B
REQUIREMENTS
Dimensions and configuration: See figure 1.
Contacts: Each contact shall contain 7 brush wires with a tolerance limit of ± 1. Each brush wire
diameter shall be .0073 to .0085 inch (0.185 mm to 0.216 mm).
Material:
Body: In accordance with MIL-DTL-55302 or approved equivalent.
Sleeve: Stainless steel in accordance with MIL-DTL-55302.
Plating: The contact termination plating shall be in accordance with table I. Brush wire plating shall
be gold in accordance with ASTM B488, type II, code C, class 1.27 over nickel in accordance with
SAE-AMS-QQ-N-290. Cut ends or brush wires need not be plated.
Part or Identifying Number (PIN): M55302/171- (contact plating indicator from table I).
TABLE I. Contact tail plating.
Indicator
Plating
1
Tin lead in accordance with SAE-AMS-P-81728, 50 to 70 percent
tin, .0001 minimum thick over copper plating.
2
Gold in accordance with ASTM B488, type II, code C,
class 0.51 over nickel in accordance SAE-AMS-QQ-N-290.
Changes from previous issue. Marginal notations are not used in this revision to identify changes with
respect to the previous issue due to the extent of the changes.
Referenced documents. In addition to MIL-DTL-55302, this document references the following:
MIL-DTL-55302/169
ASTM B488
SAE-AMS-QQ-N-290
SAE-AMS-P-81728
CONCLUDING MATERIAL
Custodians:
Preparing activity:
Air Force 11
DLA - CC
DLA CC
(Project 5935-4458-000)
Review activities:
Air Force 19, 99
NOTE: The activities listed above were interested in this document as of the date of this document.
