MIL-DTL-55302/173C
TABLE I. Dash number, number of contacts, contact type, and dimensions. 1/ 2/
A
B
C
D
E
Contact
Dash
No. of
Contact
ident. no.
number
contacts
type
1.750
1.450
1.050
9
.900
1-10
I
01
(44.45)
(36.83)
(26.67)
(22.86)
20
II
02
IV
04
VI
06
2.250
1.950
1.550
14
1.400
1-15
I
10
(57.15)
(49.53)
(39.37)
(35.56)
30
II
11
IV
13
VI
15
2.750
2.450
2.050
19
1.900
1-20
I
19
(69.85)
(62.23)
(52.07)
(48.26)
40
II
20
IV
22
VI
24
3.250
2.950
2.550
24
2.400
1-25
I
28
(82.55)
(74.93)
(64.77)
(60.96)
50
II
29
IV
31
VI
33
3.550
3.250
2.850
27
2.700
1-28
I
37
(90.17)
(82.55)
(72.39)
(68.58)
56
II
38
IV
40
VI
42
3.750
3.450
3.050
29
2.900
1-30
I
46
(95.25)
(87.63)
(77.47)
(73.66)
60
II
47
IV
49
VI
51
4.750
4.450
4.050
39
3.900
1-40
I
64
(120.65)
(113.03)
(102.87)
(99.06)
80
II
65
IV
67
VI
69
5.750
5.450
5.050
49
4.900
1-50
I
82
(146.05)
(138.43)
(128.27)
(124.46)
100
II
83
IV
85
VI
87
7.450
7.150
6.750
66
6.600
1-67
I
127
(189.23)
(181.61)
(171.45)
(167.64)
134
II
128
IV
130
VI
132
8.250
7.950
7.550
74
7.400
1-75
I
145
(209.55)
(201.93)
(191.77)
(187.96)
150
II
146
IV
148
VI
150
1/ Dimensions are in inches.
2/ Metric equivalents are given for information only.
