MIL-DTL-55302/177C
Dielectric withstanding voltage:
Sea level: 900 volts rms.
70,000 feet: 200 volts rms.
2 milliamperes maximum leakage current.
PIN: M55302/177 (and dash number from table I and type from table II).
Group qualification: See table III.
TABLE III. Group qualification.
Qualification of any of the following
Qualifies the following
Retains qualification on
connectors 1/ 2/
connectors
the following
M55302/174-***
M55302/174-***
M55302/174-***
M55302/177-***
M55302/180-***
M55302/174-***
M55302/177-***
M55302/177-***
M55302/174-***
M55302/180-***
M55302/177-***
M55302/180-***
1/ For initial qualification, connectors with the largest number of contact positions from the left hand column shall
be used to obtain qualification for parts in corresponding center column.
2/ For qualification retention data may be supplied on any two parts from the left hand column in order to retain
qualification for the parts listed in the right hand column.
CHANGES FROM PREVIOUS ISSUE: The margins of this specification are marked with vertical lines to indicate
where changes from previous issue were made. This was done as a convenience only and the Government assumes
no liability whatsoever for any inaccuracies in these notations. Bidders and contractors are cautioned to evaluate the
requirements of this document based on the entire content irrespective of the marginal notations and relationship to
the last previous issue.
Referenced documents. In addition to MIL-DTL-55302, this document references the following:
MIL-DTL-55302/31
MIL-DTL-55302/176
MIL-DTL-55302/178
MIL-DTL-55302/182
ASTM B194
ASTM B196/B196M
ASTM B197/B197M.
MS35223
MS51957
NAS1149
11
