MIL-DTL-55302/178C
Recommended circuit layout
F ± .015 (0.38 mm)
Type
Type of termination
Inches
mm
.180
4.57
I
Solder post
.120
3.05
IV
Inches
mm
Inches
mm
.001
0.03
.120
3.05
.002
0.05
.182
4.62
.005
0.13
.197
5.00
.006
0.15
.200
5.08
.008
0.20
.210
5.33
.010
0.25
.218
5.54
.015
0.38
.275
6.98
.020
0.51
.300
7.62
.025
0.64
.344
8.74
.042
1.07
.375
9.52
.050
1.27
.407
10.34
.054
1.37
.462
11.73
.085
2.16
.485
12.32
.088
2.24
.662
16.81
.100
2.54
.882
22.40
NOTES:
1. Dimensions are in inches.
2. Metric equivalents are given for information only.
3. Unless otherwise specified, tolerance is ± .005 (0.13 mm) on decimals and ± 2° on angles.
4. These connectors mate with connectors specified in MIL-DTL-55302/177.
5. Location indicators embossed on surface.
6. Numbers and indicating end cavities, letters indicating row nearest to polarizing feature, and markings every
ten positions stamped on this surface.
7. Mounting ears and hardware are purchased separately. See MIL-DTL-55302/182 for mounting hardware.
8. Chamfers shall be .015 (0.38 mm) minimum at a 45° angle ± 5°.
FIGURE 1. Connectors, pin assemblies .100 (2.54 mm) spacing, 75 through 225 contacts Continued.
