MIL-DTL-55302/181C
Keying (see MIL-DTL-55302/31):
Two keys, Part or Identifying Number (PIN) M55302/31-04, and two .086-56 UNC-2A mounting screws are
recommended. Keys and screws shall be ordered separately.
Mating and unmating: The mating force in pounds shall be the number of contacts multiplied by .250; the
withdrawal force in pounds shall be a minimum of .025 times the number of contacts and shall not exceed the
measured insertion force.
Contact resistance: No individual contact pair shall have a resistance exceeding .015-ohm initial and .020 after
testing.
Contact retention: 3 pounds, minimum.
Dielectric withstanding voltage:
Sea level: 900 volts rms.
70,000 feet: 200 volts rms.
2 milliamperes maximum leakage current.
PIN: M55302/181 (and dash number from table I and type from table II).
Group qualification: See table III.
TABLE III. Group qualification.
Qualification of any of the following
Qualifies the following
Retains qualification on
connectors 1/, 2/
connectors
the following
M55302/173-***
M55302/173-***
M55302/173-***
M55302/175-***
M55302/175-***
M55302/175-***
M55302/176-***
M55302/173-***
M55302/176-***
M55302/178-***
M55302/175-***
M55302/178-***
M55302/179-***
M55302/176-***
M55302/181-***
M55302/178-***
M55302/173-***
M55302/179-***
M55302/175-***
M55302/181-***
M55302/176-***
M55302/178-***
M55302/179-***
M55302/181-***
1/ For initial qualification, connectors with the largest number of contact positions from the left hand column shall
be used to obtain qualification for parts in corresponding center column.
2/ For qualification retention data may be supplied on any two parts from the left hand column in order to retain
qualification for the parts listed in the right hand column.
10
