MIL-DTL-55302/2F
Dash
No. of
A
B
C
D
.005
no.
contacts
basic
ref
ref
01
7
.800
.650
.450
.300
02
12
1.200
1.050
.850
.750
03
17
1.550
1.400
1.200
1.050
04
23
2.000
1.850
1.650
1.500
05
28
2.400
2.250
2.050
1.950
06
77
4.150
4.000
3.800
3.700
Inches
mm
Inches
mm
Inches
mm
Inches
mm
Inches
mm
Inches
mm
.004
.10
.0615
1.562
.136
3.45
.265
6.73
1.400
35.56
3.700
93.98
.005
.13
.0625
1.588
.150
3.81
.300
7.62
1.500
38.10
3.800
96.52
.007
.15
.065
1.65
.154
3.91
.450
11.43
1.550
39.37
4.000
101.60
.012
.30
.079
2.01
.175
4.45
.650
16.51
1.650
41.91
4.150
105.41
.026
.66
.084
2.132
.200
5.08
.750
19.05
1.850
46.99
.039
.99
.100
2.54
.240
6.10
.800
20.32
1.950
49.53
.044
1.12
.120
3.05
.245
6.22
.850
21.59
2.000
50.80
.050
1.27
.121
3.07
.250
6.35
1.050
26.67
2.250
57.15
.055
1.40
.129
3.28
.260
6.60
1.200
30.48
2.400
60.96
NOTES:
1. Dimensions are in inches.
2. Metric equivalents are given for information only.
3. Unless otherwise specified, tolerances are .005 (0.13 mm) on three place decimals and 2 on angles.
4. These connectors mate with connectors specified in MIL-DTL-55302/1 and are primarily for use with single
sided, double-sided, or multilayered printed wiring boards.
5. Positional tolerances of guide pins shall apply at datum plane X.
6. Pad(s) suitable for printed circuit board support are required. Dimensions and location(s) are optional.
FIGURE 1. Connectors, receptacle (.100 spacing) - Continued.
