MIL-DTL-55302/22F
A
B
C
D
E
F
Number
Part or
Basic
Ref
Ref
of
Identifying
±.010
±.015
±.008
contacts
Number (PIN)
M55302/22-01
92
3.426
3.240
2.900
3.000
.390
.112
M55302/22-02
92
3.426
3.240
2.900
3.000
.158
.145
M55302/22-03
92
3.426
3.240
2.900
3.000
.1465
.154
Inches
mm
Inches
mm
Inches
mm
.004
0.10
.065
1.65
.169
4.29
.005
0.13
.070
1.78
.170
4.32
.007
0.18
.071
1.80
.200
5.08
.008
0.20
.079
2.01
.348
8.84
.010
0.25
.084
2.13
.362
9.19
.012
0.30
.100
2.54
.370
9.40
.015
0.38
.120
3.05
.380
9.65
.026
0.66
.112
2.84
.390
9.91
.028
0.71
.145
3.68
2.400
60.96
.039
0.99
.154
3.91
2.900
73.66
.044
1.12
.158
4.01
3.000
76.20
.055
1.40
.161
4.09
3.240
82.30
3.426
87.02
NOTES:
1. Dimensions are in inches.
2. Metric equivalents are given for information only.
3. Unless otherwise specified, tolerances are ±.005 (0.13 mm) on three place decimals and . ±.2° on angles.
4. These connectors mate with connectors specified in MIL-DTL-55302/21 and are primarily for use with single-
sided, double-sided, or multilayered printed wiring board.
5. Positional tolerances of guide pins shall apply at datum plane X.
6. Pad(s) suitable for printed circuit boards support are optional. Dimensions and location(s) are optional.
FIGURE 1. Connectors, receptacle (.100 spacing) - Continued.
