MIL-DTL-55302/26G
Supersession data: See table I.
TABLE I. Style 1 (Internal keying) supersession data.
Superseding style
Style 1
2
(internal
(external keying)
keying)
PIN 1/
PIN
M55302/26-01
M55302/26-12
M55302/26-02
M55302/26-13
M55302/26-03
M55302/26-15
M55302/26-04
M55302/26-16
M55302/26-05
M55302/26-17
M55302/26-06
M55302/26-18
M55302/26-07
M55302/26-10
M55302/26-08
M55302/26-11
M55302/26-09
M55302/26-14
1/ Style 2 (external keying) receptacles can be
mated to existing style 1 (internal keying) plugs.
Group qualification: See table II.
TABLE II. Group qualification.
Qualification of any of the following
Qualifies the following
Retains qualification on
connectors 1/, 2/
connectors
the following
M55302/23-**
M55302/23-**
M55302/23-**
M55302/26-**
M55302/26-**
M55302/26-**
M55302/26-**
1/ For initial qualification, connectors with the largest number of contact positions from the left hand
column shall be used to obtain qualification for parts in corresponding center column.
2/ For qualification retention, data may be supplied on any two parts from the left hand column in
order to retain qualification for the parts listed in the right hand column.
** Signifies number of contacts.
Changes from previous issue: The margins of this specification are marked with vertical lines to indicate where
changes from previous issue were made. This was done as a convenience only and the Government assumes no
liability whatsoever for any inaccuracies in these notations. Bidders and contractors are cautioned to evaluate the
requirements of this document based on the entire content irrespective of the marginal notations and relationship to
the last previous issue.
