MIL-DTL-55302/4F
Dash
No. of
A
B basic
C ref
D ref
.010
no.
contacts
01
9
.750
.600
.400
.300
02
17
1.150
1.000
.800
.700
03
25
1.550
1.400
1.200
1.100
04
33
1.950
1.800
1.600
1.500
05
41
2.350
2.200
2.000
1.900
06
77
4.150
4.000
3.800
3.700
Inches
mm
Inches
mm
Inches
mm
Inches
mm
Inches
mm
Inches
mm
.002
0.05
.039
0.99
.100
2.54
.243
6.17
1.000
25.40
1.950
49.53
.004
0.10
.044
1.12
.120
3.05
.253
6.43
1.100
27.94
2.000
50.80
.005
0.13
.050
1.27
.121
3.07
.257
6.53
1.150
29.21
2.200
55.88
.007
0.18
.055
1.40
.122
3.10
.267
6.78
1.200
30.48
2.350
59.69
.008
0.20
.059
1.502
.129
3.28
.300
7.62
1.400
35.56
3.700
93.98
.009
0.23
.060
1.52
.140
3.56
.400
10.16
1.500
38.10
3.800
96.52
.010
0.25
.065
1.65
.150
3.81
.600
15.24
1.550
39.37
4.000
101.60
.012
0.30
.079
2.01
.173
4.39
.700
17.78
1.600
40.64
4.150
105.41
.026
0.66
.080
2.03
.187
4.75
.750
19.05
1.800
45.72
.028
0.71
.084
2.13
.205
5.21
.800
20.32
1.900
48.26
NOTES:
1. Dimensions are in inches.
2. Metric equivalents are given for information only.
3. Unless otherwise specified, tolerances are .005 (0.13 mm) on three place decimals and 2 on angles.
4. These connectors mate with connectors specified in MIL-DTL-55302/6 and are primarily for use with
multilayered printed wiring boards.
5. Positional tolerances of guide pins shall apply at datum plane X.
6. Pad(s) suitable for printed circuit board support are required. Dimensions and location(s) are optional.
7. The terminating side and the side opposite mating face of the plug may be open or solid construction.
FIGURE 1. Connectors, plug (.100 spacing) - Continued.
