MIL-DTL-55302/6J
Inches
mm
Inches
mm
Inches
mm
Inches
mm
Inches
mm
.001
0.03
.044
1.12
.120
3.05
.600
15.24
1.600
40.64
.004
0.10
.050
1.27
.136
3.45
.700
17.78
1.800
45.72
.005
0.13
.055
1.40
.150
3.81
.750
19.05
1.900
48.26
.006
0.15
.065
1.65
.154
3.91
.800
20.32
1.950
49.53
.007
0.18
.070
1.78
.175
4.44
1.000
25.40
2.000
50.80
.012
0.30
.071
1.80
.233
5.92
1.100
27.94
2.220
56.39
.016
0.40
.079
2.01
.245
6.22
1.150
29.21
2.350
59.69
.026
0.66
.084
2.13
.247
6.27
1.200
30.48
3.700
93.98
.027
0.69
.100
2.54
.265
6.73
1.400
35.56
3.800
96.52
.028
0.71
.112
2.84
.300
7.62
1.500
38.10
4.000
101.60
.039
0.99
.119
3.02
.400
10.16
1.550
39.37
4.150
105.41
NOTES:
1. Dimensions are in inches.
2. Metric equivalents are given for general information only.
3. Unless otherwise specified, tolerances are ± .005 (0.13 mm) on three place decimals and ± 2° on angles.
4. These connectors mate with connectors in accordance with MIL-DTL-55302/4 and MIL-DTL-55302/5, and are
primarily for use with multilayered printed wiring boards.
5. Positional tolerances of guide pins shall apply at datum plane X.
6. Pad(s) suitable for printed circuit board support are required. Dimensions and location(s) are optional.
FIGURE 1. Connectors, receptacle (.100 spacing) - Continued.
TABLE I. Dimensions and dash numbers.
Dash
No. of
A
B basic
C ref
D ref
E
F
±.010
no.
contacts
±.008
+.011
-.010
01
9
.750
.600
.400
.300
.128
.164
02
17
1.150
1.000
.800
.700
.128
.164
03
25
1.550
1.400
1.200
1.000
.128
.164
04
33
1.950
1.800
1.600
1.500
.128
.164
05
41
2.350
2.200
2.000
1.900
.128
.164
06
77
4.150
4.000
3.800
3.700
.128
.164
07
9
.750
.600
.400
.300
.090
.110
08
17
1.150
1.000
.800
.700
.090
.110
09
25
1.550
1.400
1.200
1.000
.090
.110
10
33
1.950
1.800
1.600
1.500
.090
.110
11
41
2.350
2.200
2.000
1.900
.090
.110
12
77
4.150
4.000
3.800
3.700
.090
.110
2
