MIL-DTL-55302/69D
Requirements:
Dimensions and configuration: See figure 1 and table I.
Material: In accordance with MIL-DTL-55302, except:
Body - reinforced epoxy resin or equivalent.
Bushing - monel, QQ-N-281, class B, cold drawn.
Plating: In accordance with MIL-C-39029/58.
Contact identification: Contact locations are identified numerically as shown on figure 2.
Mating and unmating: The maximum mating force, in pounds, shall be 0.5 times the number of contacts, and the
withdrawal force, in pounds, shall be a minimum of 0.08 times the number of contacts and shall not exceed the
measured insertion force.
Contact resistance: With a test current of 3 A dc, the average resistance of all contact pairs measured shall not
exceed 0.010 ohm, and no individual contact pair shall have a resistance exceeding 0.020 ohm.
Dielectric withstanding voltage:
Sea level: 1,000 volts rms, 60 Hz, ac.
High altitude: 275 volts rms, 60 Hz, ac.
Current rating: 3.0 amperes.
Insert arrangement: See figure 2.
Mating connectors: See MIL-DTL-55302/68.
Contact insertion and removal tool: See MIL-I-81969/8.
Quality conformance inspection:
Group A inspection: Delete mating and unmating.
Group B inspection: Add mating and unmating.
Part or identification number (PIN): M55302/69-(dash number form table I).
TABLE I Dash number and dimensions.
Dash
Dimensions 1/
number
+.008
+.010
+.010
E
B
D (.20)
C (.25)
A (.25)
-.000
-.000
-.000
01
1.665
1.376
1.096
.996
.688
(42.19)
(34.95)
(27.84)
(25.30)
(17.48)
02
2.246
1.960
1.686
1.581
.980
(57.05)
(49.78)
(42.82)
(40.16)
(24.89)
1/
Metric equivalent are given for information only. Millimeters are
in parentheses.
3
