MIL-DTL-55302/8F
Inches
mm
Inches
mm
Inches
mm
Inches
mm
Inches
mm
.004
0.10
.039
0.99
.180
4.57
.600
15.24
1.600
40.64
.005
0.13
.044
1.12
.200
5.08
.700
17.78
1.800
45.72
.006
0.15
.050
1.27
.255
6.48
.800
20.32
1.900
48.26
.007
0.18
.055
1.40
.265
6.73
1.000
25.40
2.000
50.80
.008
0.20
.065
1.52
.300
7.62
1.100
27.94
2.200
55.88
.012
0.30
.070
2.01
.345
8.76
1.200
30.48
2.400
60.96
.026
0.66
.071
1.80
.355
9.02
1.400
35.56
.028
0.71
.079
2.01
.400
10.16
1.500
38.10
NOTES:
1. Dimensions are in inches.
2. Metric equivalents are given for information only.
3. Unless otherwise specified, tolerances are ± .005 (0.13 mm) on three place decimals and ± 2° on angles.
4. These connectors mate with connectors specified in MIL-DTL-55302/7 and are primarily for use with
multilayered printed wiring boards.
5. Positional tolerances of guide pins shall apply at datum plane X.
6. Pad(s) suitable for printed circuit board support are required. Dimensions and location(s) are optional.
FIGURE 1. Connectors, receptacle (.100 spacing) - Continued.
TABLE 1. Dimensions and dash numbers.
Dash
No. of
A
B
C
D
no.
contacts
basic
ref
ref
.800 ± .005
.600
.300
.400
01
13
(20.32 ± 0.127)
(15.24)
(7.62)
(10.16)
1.200 ± .005
1.000
.700
.800
02
25
(30.48 ± 0.127)
(25.40)
(17.78)
(20.32)
1.600 ± .005
1.400
1.100
1.200
03
37
(40.64 ± 0.127)
(35.56)
(27.94)
(30.48)
2.000 ± .008
1.800
1.500
1.600
04
49
(50.80 ± .203)
(45.72)
(30.10)
(40.64)
2.400 ± .008
2.200
1.900
2.000
05
61
(60.96 ± .203)
(55.88)
(48.26)
(50.80)
NOTES:
1. Dimensions are in inches.
2. Metric equivalents in parentheses are given for information only.
2
