MIL-DTL-55302/93F
Inches
mm
Inches
mm
.003
0.08
.185
4.70
.005
0.13
.250
6.35
.007
0.18
.270
6.86
.015
0.38
.276
7.01
.086
2.18
.320
8.13
.091
2.31
.340
8.64
.098
2.49
.400
10.16
.100
2.54
.410
10.41
.120
3.05
.462
11.73
.125
3.18
.625
15.88
.138
3.51
.163
4.14
Dash
Number
Dimensions
number
of
A
B
C
D
E
F
G
L
contacts
±.006
±.006
±.006
±.006
±.006
±.006
(.015)
(.015)
(.015)
(.015)
(.015)
(.015)
01
24
1.100
1.250
1.240
1.400
1.900
2.200
1.260
1.252
(27.94)
(31.75)
(31.50)
(35.56)
(48.26)
(55.88)
(32.00)
(31.80
02
28
2.300
2.450
2.440
2.600
3.100
3.400
2.460
2.452
(58.42)
(62.23)
(61.98)
(66.04)
(78.74)
(86.38)
(62.48)
(62.28)
03
72
3.500
3.650
3.640
3.800
4.300
4.600
3.600
3.652
(88.90)
(92.71)
(92.46)
(96.52)
(109.22)
(116.84)
(92.96)
(92.76)
04
96
4.700
4.850
4.840
5.000
5.500
5.800
4.860
4.852
(119.38)
(123.19)
(122.94)
(127.00)
(139.70)
(147.32)
(123.44)
(123.24)
FIGURE 1. Connector, plug (.100 inch spacing) Continued.
2
