MIL-DTL-55302/95E
Inches
mm
Inches
mm
.003
0.08
.185
4.70
.005
0.13
.250
6.35
.007
0.18
.270
6.86
.015
0.38
.276
7.01
.086
2.18
.320
8.13
.091
2.31
.340
8.64
.096
2.44
.400
10.16
.098
2.49
.410
10.41
.100
2.54
.462
11.73
.120
3.05
.560
14.22
.125
3.18
.625
15.88
.138
3.51
.163
4.14
Dash
Number
Dimensions
number
of
L
F
G
E
C
D
B
A
contacts
±.006
±.006
±.006
±.006
±.006
±.006
(.015)
(.015)
(.015)
(.015)
(.015)
(.015)
01
24
1.100
1.250
1.240
1.400
1.900
2.200
1.260
1.252
(27.94)
(31.75)
(31.50)
(35.56)
(48.26)
(55.88)
(32.00)
(31.80
02
28
2.300
2.450
2.440
2.600
3.100
3.400
2.460
2.452
(58.42)
(62.23)
(61.98)
(66.04)
(78.74)
(86.38)
(62.48)
(62.28)
03
72
3.500
3.650
3.640
3.800
4.300
4.600
3.600
3.652
(88.90)
(92.71)
(92.46)
(96.52)
(109.22)
(116.84)
(92.96)
(92.76)
04
96
4.700
4.850
4.840
5.000
5.500
5.800
4.860
4.852
(119.38)
(123.19)
(122.94)
(127.00)
(139.70)
(147.32)
(123.44)
(123.24)
NOTES:
1. Dimensions are in inches.
2. Metric equivalents are given for general information only.
3. Unless otherwise specified, tolerances are ±.010 (0.25 mm).
4. Dimensions are .162 (4.11 mm) hex across the flats by .052 deep (1.32 mm) 4 places.
5. Keying sockets shown are in positions 1 and A.
FIGURE 1. Connector, plug (.100 inch spacing) Continued.
