MIL-DTL-55302/96F
Inches
mm
Inches
mm
.001
0.03
.185
4.70
.003
0.08
.235
5.97
.005
0.13
.250
6.35
.007
0.18
.270
6.86
.015
0.38
.276
7.01
.086
2.18
.320
8.13
.091
2.31
.340
8.64
.096
2.44
.400
10.16
.098
2.49
.410
10.41
.100
2.54
.450
11.43
.102
2.59
.462
11.73
.120
3.05
.560
14.22
.125
3.18
.625
15.88
.138
3.51
.163
4.14
Dimensions
Dash
Number
of
number
M
F
G
E
C
D
B
A
contacts
±.006
±.006
±.006
±.006
±.006
±.006
(.015)
(.015)
(.015)
(.015)
(.015)
(.015)
01
24
1.100
1.236
1.240
1.400
1.900
2.200
1.260
1.270
(27.94)
(31.39)
(31.50)
(35.56)
(48.26)
(55.88)
(32.00)
(32.26)
02
28
2.300
2.436
2.440
2.600
3.100
3.400
2.460
2.470
(58.42)
(61.87)
(61.98)
(66.04)
(78.74)
(86.38)
(62.48)
(62.74)
03
72
3.500
3.636
3.640
3.800
4.300
4.600
3.600
3.670
(88.90)
(92.35)
(92.46)
(96.52)
(109.22)
(116.84)
(92.96)
(93.22)
04
96
4.700
4.836
4.840
5.000
5.500
5.800
4.860
4.870
(119.38)
(122.83)
(122.94)
(127.00)
(139.70)
(147.32)
(123.44)
(123.70)
NOTES:
1. Dimensions are in inches.
2. Metric equivalents are given for information only.
3. Unless otherwise specified, tolerances are ± .010 (0.25 mm).
4. Dimensions are .162 (4.11 mm) hex across the flats by .052 deep (1.32 mm) 4 places.
5. Keying sockets shown are in positions 4 and D.
FIGURE 1. Connector receptacle (.100 inch spacing) Continued.
