MIL-DTL-55302/99D
NOTES:
1. Dimensions are in inches.
2. Metric equivalents are given for general information only.
3. Metric equivalents are in parentheses.
FIGURE 2. Typical cutout for receptacle in nonconductive chassis.
TABLE I. Dash number and dimensions.
Dash
Dimensions 2/
Number
number 1/
of contacts
A
B
C
D
E
±.010
Ref
01
18
.850
1.150
1.300
1.006
1.150
(21.59)
(29.21)
(33.02)
(25.55)
(29.21)
02
30
1.450
1.750
1.900
1.606
1.750
(36.83)
(44.45)
(48.26)
(40.79)
(44.45)
03
36
1.750
2.050
2.200
1.906
2.050
(44.45)
(52.07)
(55.88)
(48.41)
(52.07)
04
42
2.050
2.350
2.500
2.206
2.350
(52.07)
(59.69)
(63.50)
(56.03)
(59.69)
05
54
2.650
2.950
3.100
2.806
2.950
(67.31)
(74.93)
(78.74)
(71.27)
(74.93)
06
72
3.550
3.850
4.000
3.706
3.850
(90.17)
(97.79)
(101.60)
(94.13)
(97.79)
1/ See requirements for complete Part or Identifying Number (PIN) when keying pin is required.
2/ Dimensions are in inches. Metrics are in parentheses.
3
