MIL-DTL-641/10D
TABLE I. Dimensions.
Center to center dimensions for
multiple mounting on panel
In direction of
At right angle to
Type
pileup (min)
pileup (min)
JJ-083
1.188
.688
REQUIREMENTS:
Dimensions and configuration: See figure 1.
Insertion and withdraw forces shall be as follows.
Insertion force -
7 pounds (maximum).
Withdraw force -
1.5 pounds (minimum).
-
7 pounds (maximum).
Spring life test is applicable. Test plug TP68, in accordance with MIL-DTL-641, shall be used.
Ground terminal shall be placed on top of pileup, as shown in schematic.
The Part or Identifying Number (PIN) consists of the letter M, the basic specification number, the
specification sheet number, and a number for jack type. (see table II)
M
641
/10
-1
Type designation
Specification sheet number
Specification number
M prefix
PIN example: M641/10-1 indicates type JJ-083 telephone jack.
TABLE II. PIN.
Switching action upon
Dash number
Type
Connection
Mounting
insertion of plug
1
JJ-083
Tip, ring, and sleeve
Single lug or bushing
Two breaks
Marginal notations are not used in this revision to identify changes with respect to the previous issue due
to the extent of the changes.
Referenced documents. This document references MIL-DTL-641.
