MIL-DTL-641/13D
Inches
mm
Inches
mm
Inches
mm
.002
0.05
.094
2.39
0.688
17.48
.005
0.13
0.2515
6.39
0.750
19.05
.015
0.38
0.375
9.53
0.781
19.84
.016
0.41
0.500
12.70
1.015
25.78
.020
0.51
0.562
14.27
1.312
33.32
.062
1.57
0.625
15.88
1.750
44.45
NOTES:
1. Dimensions are in inches.
2. Metric equivalents are given for information only.
3. The jacks are not generally used for multiple mounting.
4. The schematic shows required switching operations but does not indicate a required mechanical
arrangement of the parts.
FIGURE 1. Dimensions and configuration - Continued.
TABLE I. Dimensions.
Type
Dimension
A
JJ-92
.688
JJ-93
.781
JJ-96
.562
JJ-97
.625
REQUIREMENTS:
Dimensions and configuration: See figure 1 and table I.
Insertion and withdraw forces shall be as follows.
Insertion force -
7 pounds (maximum).
Withdraw force -
1.5 pounds (minimum).
-
7 pounds (maximum).
Spring life test is applicable. Test plug TP55, in accordance with MIL-DTL-641, shall be used.
The Part or Identifying Number (PIN) consists of the letter M, the basic specification number, the
specification sheet number, and a number for jack type. (see table II)
M
641
/13
-1
Type designation
Specification sheet number
Specification number
M prefix
PIN example: M641/13-1 indicates type JJ-092 telephone jack.
2
