MIL-DTL-641/21B
TABLE I. PIN.
Part
Terminal
Connection
Mounting
Switching action
number
1
None
Wirewrap
2
None
Solder lug
3
4 breaks
Wirewrap
4
4 breaks
Solder lug
5
4 breaks connected
Wirewrap
6
4 breaks connected
Solder lug
Tip, ring
Double
and sleeve
lug
7
2 breaks connected
Wirewrap
8
2 breaks connected
Solder lug
9
4 breaks connected, 1 make
Wirewrap
10
4 breaks connected, 1 make
Solder lug
11
5 breaks, 4 connected
Wirewrap
12
5 breaks, 4 connected
Solder lug
TABLE II. Mating plugs.
Dash number
Mating plug
-1
-2
-3
-4
-5
-6
M642/13-1, -2, -3, -4
-7
-8
-9
-10
-11
-12
Marginal notations are not used in this revision to identify changes with respect to the previous issue due
to the extent of the changes.
Referenced documents. This document references MIL-DTL-641.
