INCH-POUND
MIL-DTL-641/3E
18 October 2013
SUPERSEDING
MIL-J-641/3D
03 July 1973
DETAIL SPECIFICATION SHEET
JACKS, TELEPHONE
TYPES JJ-022, JJ-042, JJ-073, JJ-074, JJ-075, JJ-077 AND JJ-078
This specification is approved for use by all Departments and
Agencies of the Department of Defense.
The requirements for acquiring the product described herein shall
consist of this specification sheet and MIL-DTL-641.
Inches
mm
Inches
mm
Inches
mm
.002
0.05
0.438
11.13
0.781
19.84
.005
0.13
0.448
11.38
0.844
21.44
.015
0.38
0.500
12.70
0.859
21.82
.040
1.02
0.562
14.27
0.906
23.01
.062
1.57
0.594
15.09
0.922
23.42
.094
2.39
0.625
15.88
1.015
25.78
.156
3.96
0.656
16.66
1.094
27.79
0.2515
6.39
0.719
18.26
1.250
31.75
0.281
7.14
0.750
19.05
2.953
75.01
0.375
9.53
NOTES:
1. Dimensions are in inches.
2. Metric equivalents are given for information only.
3. Jacks may be multiple mounted on a panel in accordance with the minimum center-to-center dimensions
specified in table I.
4. Arrangement of contact spring lifters is optional.
FIGURE 1. Dimensions and configuration.
AMSC N/A
FSC 5935
