MIL-DTL-641/7D
REQUIREMENTS:
Dimensions and configuration: See figure 1.
Insertion and withdrawal forces. The insertion and withdrawal forces shall be as follows:
Insertion force - - - - - - - - - 6 pounds (maximum).
Withdrawal force - - - - - - - 2 pounds (minimum).
6 pounds (maximum).
Spring life. Test plug TP291, in accordance with MIL-J-641.
Voltage breakdown. Voltage breakdown shall not occur between springs when the mating plug is inserted.
Evidence of failure shall be checked using 500 volts ac.
Qualification: Qualification is not required for this specification sheet. First article inspection shall be a visual and
mechanical inspection in accordance with MIL-J-641.
PIN: M641/7 (dash number from table I)
TABLE I. Types of telephone jacks.
Dash
Switching action upon
Color
no.
Type
Connection
Mounting
Insertion of plug
1
JJ-048
Miniature two-pin
Cord
None
Black
2
Red
Changes from previous issue. Marginal notations are not used in this revision to identify changes with respect to
the previous issue due to the extent of the changes.
Referenced documents. This document references MIL-J-641.
CONCLUDING MATERIAL
Custodians:
Preparing activity:
Army CR
DLA CC
Navy EC
Air Force 85
DLA CC
Review activities:
(Project 5935-2012-204)
Navy MC
Air Force 19
NOTE: The activities listed above were interested in this document as of the date of this document. Since
organizations and responsibilities can change, you should verify the currency of the information above using the
ASSIST Online database at https://assist.dla.mil
