MIL-DTL-642/11C
Inch/mm conversion chart
Inches
mm
Inches mm
Inches
mm
.002
.05
.165
4.19
.885
22.48
.003
.08
.187
4.75
.980
24.89
.005
.13
.244
6.20
1.000
25.40
.008
.20
.250
6.35
1.109
28.17
.015
.38
.500
12.70
1.187
30.15
.046
1.17
.625
15.88
1.468
37.29
.062
1.57
.687
17.45
3.062
77.77
.145
3.68
.843
21.41
NOTES:
1. Dimensions are in inches.
2. Metric equivalents (to nearest .01 mm) are given for general information only.
3. Unless otherwise specified, tolerance is ± .010 (0.25 mm).
4. After assembly, the eccentricity between the end of the shank and the tip of the plug shall not
exceed .008 (.20 mm) TIR (total indicator reading).
5. Thread shall be in accordance with FED-STD-H28.
6. Screw MS35214-22 in accordance with NASM35214.
FIGURE 1. Dimensions and configurations - Continued.
