MIL-DTL-642/12C
Inches
mm
Inches
mm
Inches
mm
Inches
mm
Inches
mm
.002
0.05
.030
0.76
.081
2.06
.0978
2.48
.1113
2.83
.005
0.13
.031
0.79
.0825
2.10
.0983
2.50
.112
2.84
.014
0.36
.046
1.17
.0848
2.15
.099
2.51
.124
3.15
.015
0.38
.047
1.19
.086
2.18
.104
2.64
.125
3.18
.020
0.51
.072
1.83
.0938
2.38
.1068
2.71
.144
3.66
.026
0.66
.078
1.98
.0954
2.42
NOTES:
1. Dimensions are in inches.
2. Metric equivalents are given for information only.
FIGURE 1. Dimensions and configuration - Continued.
REQUIREMENTS:
Dimensions and configuration: See figure 1.
Screw material shall be in accordance with MIL-DTL-642.
Screw thread shall be in accordance with MIL-DTL-642.
2
