MIL-DTL-642/2C
Inches
mm
Inches
mm
Inches
mm
Inches
mm Inches
mm Inches
mm
.002
0.05
.099
2.51
.250
6.35
.419
10.64 .640
16.26 1.125
28.58
.003
0.08
.130
3.30
.301
7.65
.445
11.30 .712
18.08 1.144
29.06
.008
.020
.143
3.63
.3125
7.94
.593
15.06 .842
21.39 2.041
51.84
.015
0.38
.170
4.32
.331
8.41
.625
15.88 .939
23.85 2.062
52.37
.045
1.14
.210
5.33
.336
8.53
.632
16.05 1.000
25.40 3.203
81.36
NOTES:
1. Dimensions are in inches.
2. Metric equivalents are given for information only.
3. Unless otherwise specified, tolerance is ±.010 (.25mm).
4. After assembly, the eccentricity between the end of the shank and the tip of the plug shall not exceed
.008 inch (.20mm) total indicator reading (TIR).
FIGURE 1. Dimensions and configuration - Continued.
REQUIREMENTS:
Dimensions and configuration: See figure 1.
Shell shall be plastic in accordance with MIL-DTL-642.
Terminal screws shall be .086-64 UNF-2A in accordance with MIL-DTL-642/12.
Shell screws shall be .099-48 UNC-2A in accordance with MIL-DTL-642/12.
2
