MIL-DTL-642/7B
Inches
mm
Inches
mm
Inches
mm
Inches mm Inches
mm
.002
0.05
.058
1.47
.130
3.30
.312
7.92
.531
13.49
.008
0.20
.062
1.57
.187
4.75
.364
9.25
.808
20.52
.015
0.38
.080
2.03
.218
5.54
.375
9.53
.812
20.62
.020
0.51
.086
2.18
.240
6.10
.393
9.98 1.312
33.32
.031
0.79
.094
2.39
.308
7.82
.408 12.19 1.625
41.28
.040
1.02
.125
3.18
NOTES:
1. Dimensions are in inches.
2. Metric equivalents are given for information only.
3. Unless otherwise specified, tolerance is ±.010 (.25mm).
FIGURE 1. Dimensions and configuration - Continued.
REQUIREMENTS:
Dimensions and configuration: See figure 1.
Shell shall be black plastic in accordance with MIL-DTL-642.
Torque test: Not applicable.
The Part or Identifying Number (PIN) consists of the letter M, the basic specification number, the
specification sheet number, and dash number for plug type. (see table I)
M
642
/7
-
1
Type designation
Specification sheet number
Specification number
M prefix
PIN example: M642/7-1 indicates type PJ-292 telephone plug.
2
