MIL-DTL-83413/6C
REQUIREMENTS:
Material:
Inserts: Brass in accordance with ASTM-B36/ B36M and ASTM-B121/B121M.
Insert detents: Beryllium copper in accordance with ASTM-B196/ B196M, ASTM-B197/ B197M and
ASTM-B194.
Housing: Stainless steel in accordance with SAE-AMS-S-7720, 300 series composition, condition A,
passivated in accordance with ASTM-A967 or SAE-AMS-QQ-P-35.
Dentent action: Shall be provided for the mating plug.
Finish: Cadmium plate in accordance with SAE-AMS-QQ-P-416, type II, class 2, or aluminum coating, or
zinc in accordance with ASTM-B633.
Contact resistance: Shall not exceed 5.0 milliohms.
Durability: 3,000 cycles.
Mounting nut: Shall be supplied with housing type A.
Fluid immersion: Not applicable to housing type B.
Mating plug: In accordance with MIL-DTL-83413/4.
Part or Identifying Number (PIN):
M83413 /6-
1
A
F
Basic specification
Specification sheet
Inserts
0 - none
1 - hex flange
2 - circular flange
Housing
0 - none
A - coupling nut mounting
B - rivet mounting
Finish
C Cadmium
Z Zinc
A - Aluminum
3
