MIL-DTL-83503/21D
Inches
mm
Inches
mm
Inches
mm
Inches
mm
6.10
.240
1.3
.05
0.64
.025
0.08
.003
6.35
.250
1.52
.060
0.76
.030
0.13
.005
7.37
.290
2.0
.08
0.81
.032
0.15
.006
7.9
.31
2.54
.100
0.86
.034
0.25
.010
8.13
.32
2.67
.105
0.89
.035
0.3
.01
8.94
.352
2.95
.116
1.07
.042
0.30
.012
14.55
.573
3.18
.125
1.14
.045
0.38
.015
15.49
.610
3.60
.142
1.27
.050
0.51
.020
33.0
1.3
4.1
.16
NOTES:
1. Dimensions are in inches.
2. Metric equivalents are given for information only.
3. Unless otherwise specified tolerances are ± .005 inch (0.13 mm) for three place decimals and
± .01 inch (0.3 mm) for two place decimals.
4. For 10 and 14 position connectors the polarizing feature on this end is non-existent.
5. Two thread cutting screws, No. 4-24 (1/4 inch long) type BG are provided.
6. Pin length for printed wiring board (PWB) thickness of is as follows:
Pin length
Pin length
PWB thickness
Min
Max
inch
inch
inch
(mm)
(mm)
(mm)
.062 (1.57)
.089 (2.26)
.116 (2.95)
.125 (3.18)
.152 (3.86)
.178 (4.52)
7. Solderless wrappost, pin length shall be .610 ±.015 inch (15.49 ±0.38 mm).
FIGURE 1. Dimensions and configuration - Continued.
3
