INCH-POUND
MIL-DTL-83505/6E
25 September 2001
SUPERSEDING
MIL-S-83505/6D
25 September 1991
DETAIL SPECIFICATION SHEET
SOCKETS (LEAD, ELECTRONIC COMPONENTS)
(TYPE VI, SOLDERLESS SPRING CONTACT)
This specification is approved for use by all
Departments and Agencies of the department of Defense.
The requirements for acquiring the product described herein shall
consist of this specification and MIL-DTL-83505.
90° ±21/2°
15° ±2°
B
45° ±5°
D
.014 ±.003
C
C
L
45° ±5°
A
FIGURE 1. Socket, lead, (type VI solderless spring contact).
AMSC N/A
1 of 3
FSC 5935
DISTRIBUTION STATEMENT A. Approved for public release; distribution is unlimited
