MIL-DTL-83505/8B
REQUIREMENTS
Qualification:
Group qualification: Shall be as specified in table I.
Dimensions and configuration: Shall be in accordance with figures 1 and 2 and table II.
Solderless wrappost geometry: The solderless wrappost geometry shall be in accordance with
figures 2 and 3.
TABLE I. Group qualification.
Dash number
Qualification tests
-001, -002, -009, and -010
Require all qualification tests of MIL-DTL-83505.
(as applicable)
-003 through -006 and -011
Visual and mechanical tests of MIL-DTL-83505 and
through -014 (as applicable)
qualification of -001, or -002, or -009, or -010.
-007 and -008 (as
Groups 1,2, and 5 or qualification table of MIL-DTL-83505
applicable)
and qualification of -001, or -002, or -009, or -010.
TABLE II. Interface dimensions and finish. 1/
Recommended
Accepts pin
Dash
mounting
Sleeve plating
number
hole dia
Length
Diameter
.001 inch (.025 mm)
.175 (4.44)
.021 (0.53)
Gold
-001 and -009
.055 (1.40)
-002 and -010
Tin/lead
.125 (3.18)
.016 (0.41)
.175 (4.44)
.021 (0.53)
Gold
-003 and -011
.055 (1.40)
-004 and -012
Tin/lead
.125 (3.18)
.016 (0.41)
.175 (4.44)
.021 (0.52)
Gold
-005 and -013
.055 (1.40)
-006 and -014
Tin/lead
.125 (3.18)
.016 (0.41)
.281 (7.14)
.030 (0.76)
Gold
-007
.076 (1.93)
Tin/lead
-008
.156 (3.96)
.020 (0.51)
1/ Metric equivalents are in parenthesis.
