MIL-DTL-83513/1H
REQUIREMENTS:
Dimensions and configurations: See figure 1. This specification sheet describes the pin side of a rectangular
metal shell connector. This connector uses reverse gender contact, i.e., the live pin recessed in the insulator
with the static socket protruding from a shrouded interface.
Material and finish:
Shell: The requirements for shell materials shall be in accordance with MIL-DTL-83513.
Contact identification: See figure 2 for contact layout identification.
Contact connection: The pin contact (being recessed in the insulator) is normally connected to the live side
of the circuit.
Current rating, maximum: 3 amperes per contact.
Mounting and mating hardware: Mounting hardware is to be ordered separately. Insert arrangements A
through G, are in accordance with MIL-DTL-83513/5, configurations A and B. Insert arrangement H, is in
accordance with MIL-DTL-83513/5, configuration C.
Mating receptacle: Mating receptacle in accordance with MIL-DTL-83513/2 or MIL-DTL-83513/4.
Part or Identifying Number (PIN): PIN shall consist of the letter M, the basic number of the specification
sheet, a letter from the insert column and the shell finish.
M83513/01 -
A
C
Specification sheet
Insert arrangement
Shell finish
(Interface critical)
(see figure 2)
A = Pure electrodeposited aluminum
A=9
C = Cadmium
B = 15
K = Zinc nickel
C = 21
D = 25
N = electroless nickel
(space applications only)
E = 31
F = 37
P = Passivated Stainless Steel
T = Nickel Fluorocarbon Polymer
G = 51
H = 100
Changes from previous issue. The margins of this specification are marked with vertical lines to indicate
where changes from the previous issue were made. This was done as a convenience only and the
Government assumes no liability whatsoever for any inaccuracies in these notations. Bidders and
contractors are cautioned to evaluate the requirements of this document based on the entire content
irrespective of marginal notations and relationship to the last previous issue.
