MIL-DTL-83513/3J
5/ Color coding in accordance with MIL-STD-681, system I, except the appropriate color code shall be
the individual contact cavity number minus 1 for contact positions 1 through 10 only, 11 through 20,
etc. For example:
Pin number
Identification
4
3
9
8
21
0
31
0
77
6
100
9
6/ Lead length tolerance +0.2, -0.0 inch.
7/ Contact and wire may be a single piece design.
8/ Corrosion has been experienced on M83513 connectors that are prewired with SAE AS22759/33
and stored in a sealed environment. CAUTION SHOULD BE EXCERCISED WHEN USING THIS
WIRE.
9/ Pure tin. The use of pure tin is prohibited. Tin content used in connector materials shall not exceed
97 percent, and an alloy material shall be chosen to inhibit the growth of tin whiskers.
Changes from previous issue. The margins of this specification are marked with vertical lines to indicate
modifications generated by this amendment. This was done as a convenience only and the Government
assumes no liability whatsoever for any inaccuracies in these notations. Bidders and contractors are
cautioned to evaluate the requirements of this document based on the entire content irrespective of
marginal notations and relationship to the last previous issue.
Referenced documents. In addition to MIL-DTL-83513, this document references the following:
A-A-59551
MIL-STD-681
MIL-DTL-83513/2
SAE AS22759/33
MIL-DTL-83513/4
MIL-DTL-83513/5
8
