MIL-DTL-83513/9F
Example of Part or Identifying Number (PIN):
M83513/09 -
A
01 1/
Specification sheet number
Insert arrangement
Wire
(see figure 2)
type
A=9
01 = M22759/11-26-9, 18 inches long 2/ /
B = 15
02 = M22759/11-26-9, 36 inches long 2/ /
C = 21
03 = M22759/11-26-( ), 18 inches long 2/ 3/
D = 25
04 = M22759/11-26-( ), 36 inches long 2/ 3/
E = 31
05 = A-A-59551, type S, 25 AWG, except shall be gold
F = 37
plated 10 microinches; 0.5 inch long 4/ 5/
G = 51
06 = A-A-59551, type S, 25 AWG, except shall be gold
plated 10 microinches; 1.0 inch long 4/ 5/
07 = A-A-59551, type S, 25 AWG, tin plated 100
microinches; 0.5 inch long 4/ 5/ 6/
08 = A-A-59551, type S, 25 AWG, tin plated 100
microinches; 1.0 inch long 4/ 5/ 6/
09 = M22759/33-26-9, 18 inches long 2/
10 = M22759/33-26-9, 36 inches long 2/
11 = M22759/33-26-( ), 18 inches long 2/ 3/
12 = M22759/33-26-( ), 36 inches long 2/ 3/
13 = M22759/11-26-9, 72 inches long 2/
14 = M22759/11-26-( ), 72 inches long 2/
15 = M22759/33-26-9, 72 inches long 2/
16 = M22759/33-26-( ), 72 inches long 2/
17 = 04035-26A-9, 18 inches long 2/
18 = 04035-26A-9, 36 inches long 2/
19 = 04035-26A-9, 72 inches long 2/
20 = 04035-26A-( ), 18 inches long 2/ 3/
21 = 04035-26A-( ), 36 inches long 2/ 3/
22 = 04035-26A-( ), 72 inches long 2/ 3/
1/ These connectors have leads attached of which wire type, wire size, wire color, and lead length are
specified in PIN.
2/ Lead length tolerance +1.0, -0.0 inch.
3/ Color coding in accordance with MIL-STD-681, system I, except the appropriate color code shall be
the individual contact cavity number minus 1 for contact positions 1 through 10, repeat this color
sequence for contact positions 11 through 20, etc. For example:
Pin number
Identification
4
3
9
8
21
0
31
0
47
6
4/ Lead length tolerance +0.2, -0.0 inch.
5/ Contact and wire may be welded or a single piece design.
6/ Pure tin. The use of pure tin is prohibited. Tin content used in connector materials shall not
exceed 97 percent, and an alloy material shall be chosen to inhibit the growth of tin whiskers.
