MIL-DTL-83517/2A
ENGINEERING PARAMETERS
Nominal impedance: 50 ohms.
Voltage rating: 335 V rms maximum at sea level.
150 V rms maximum at 70,000 feet.
Frequency range: 0 to 18.0 GHz.
Temperature rating: -65ºC to 105ºC.
REQUIREMENTS
Design and construction: See figures 1 and 2; table I and MIL-STD-348.
Force to engage and disengage:
Torque 2 inch-pounds maximum.
Longitudinal force Not applicable.
Coupling proof torque: 15 inch-pounds minimum.
Inspection note: For each test of threaded coupling connector where the test is performed on mated
pairs, the pairs shall be torqued to 7 to 10 inch-pounds.
TABLE I. PIN and characteristics.
PIN
Connector
Characteristics
M83517/2-
figure no.
31001
1
2 hole flange mount.
.020 inch (0.51 mm) wide tab.
31002
1
2 hole flange mount.
.050 inch (1.27 mm) wide tab.
31003
2
4 hole flange mount.
.020 inch (0.51 mm) wide tab.
31004
2
4 hole flange mount.
.050 inch (1.27 mm) wide tab.
32001
1
2 hole flange mount.
.020 inch (0.51 mm) wide tab.
32002
1
2 hole flange mount.
.050 inch (1.27 mm) wide tab.
32003
2
4 hole flange mount.
.020 inch (0.51 mm) wide tab.
32004
2
4 hole flange mount.
.050 inch (1.27 mm) wide tab.
Permeability of nonmagnetic materials: Applicable.
Seal:
Hermetic sealed connectors: Not applicable.
Pressurized and weatherproof connectors: Not applicable.
Insulation resistance: 5,000 megohms minimum in accordance with test procedure EIA-364-21.
Center contact retention:
Axial force: 6 pounds minimum.
Torque: 4 inch-ounces minimum.
3
