MIL-DTL-83517/5A
NOTES:
1. Dimensions are in inches.
2. Metric equivalents are given for information only.
3. All undimensioned pictorial configurations are for reference purposes only.
4. Number two screws are suggested for mounting.
FIGURE 1. Series SMA, pin contact, (4 hole) flange mounted
receptacle, extended dielectric Continued.
ENGINEERING PARAMETERS
Nominal impedance: 50 ohms.
Voltage rating: 335 V rms maximum at sea level.
150 V rms maximum at 70,000 feet.
Frequency range: 0 to 18.0 GHz.
Temperature rating: -65º to 105ºC.
REQUIREMENTS
Design and construction: See figure 1, table I and MIL-STD-348.
Force to engage and disengage:
Torque 2 inch-pounds maximum.
Longitudinal force Not applicable.
Coupling proof torque: 15 inch-pounds minimum.
Inspection note: For each test of threaded coupling connector where the test is performed on mated
pairs, the pairs shall be torqued to 7 to 10 inch-pounds.
TABLE I. Part or Identifying Number (PIN) and characteristics.
PIN
Connector
Characteristics
M83517/5-
figure no.
31001
1
4 hole flange receptacle, .050 inch (1.27 mm) diameter terminal
Permeability of nonmagnetic materials: Applicable.
Seal:
Hermetic sealed connectors: Not applicable.
Pressurized and weatherproof connectors: Not applicable.
Insulation resistance: 5,000 megohms minimum in accordance with test procedure EIA-364-21.
2
