MIL-DTL-83723/59D
NOTES:
1. Dimensions are in inches.
2. Metric equivalents are given for information only.
3. Metric equivalents are in parentheses.
4. Unless otherwise specified, tolerances shall be ± .005 (.13 mm) for three place decimals.
5. The method of attachment is optional. The fastener shall not become loose or be damaged when
subjected to a straight axial pull of 5 lb minimum on the chain or rope. The chain or rope shall
rotate freely on the fastener.
6. Coupling assurance indicator shall be provided in accordance with MIL-DTL-83723.
7. These parts are intended for use as protective covers for MIL-DTL-83723, series III, and
MIL-DTL-26500 bayonet coupling connector plugs.
FIGURE 2. Protective cover, plug, bayonet coupling M83723/59-2 - Continued.
REQUIREMENTS:
Dimensions and configurations: See figures 1 and 2.
Materials:
Cover
Aluminum alloy.
Gasket
Silicone elastomer.
Sash chain
Stainless steel, passivated, in accordance with RR-C-271, type II, class 3.
Fastener
Stainless steel, passivated.
Rope
Insulated, stainless steel, passivated, braided or stranded. Insulation shall withstand
200°C environment.
Gasket shall be bonded to cover or mechanically retained in cover.
The chain or rope shall rotate freely on the fastener.
Termination style: See table I.
TABLE I. Termination style.
Letter designators
Chain and rope length
C
with a chain length of 5.0 (127.00 mm) + .25 (6.35 mm)
N
without chain
R
with a rope length of 5.0 (127.00 mm) + .25 (6.35 mm)
P
with a chain length of 8.0 (203.20 mm) + .25 (6.35 mm)
T
with a rope length of 8.0 (203.20 mm) + .25 (6.35 mm)
5
