MIL-DTL-83723/60E
Inches
mm
Inches
mm
Inches
mm
Inches
mm
.002
0.05
.078
1.98
.125
3.18
.442
11.23
.005
0.13
.087
2.21
.281
7.14
.618
15.70
.010
0.25
.115
2.92
.283
7.19
4.750
120.65
.047
1.19
.116
2.95
.409
10.40
5.250
133.35
A
B dia
C dia
G
H dia
max outside
min
+ .005
min
min
Shell size
diameter coupling
- .000
8
.776 (19.71)
.632 (16.05)
.540 (13.72)
.079 (2.01)
.079 (2.01)
10
.906 (23.01)
.760 (19.30)
.662 (16.81)
.094 (2.39)
.094 (2.39)
12
1.078 (27.38)
.930 (23.62)
.832 (21.13)
.094 (2.39)
.094 (2.39)
14
1.141 (28.98)
.999 (25.37)
.901 (22.89)
.094 (2.39)
.094 (2.39)
16
1.266 (32.16)
1.126 (28.60)
1.028 (26.11)
.094 (2.39)
.094 (2.39)
18
1.375 (34.93)
1.232 (31.29)
1.134 (28.80)
.094 (2.39)
.094 (2.39)
20
1.510 (38.35)
1.357 (34.47)
1.261 (32.03)
.094 (2.39)
.094 (2.39)
22
1.625 (41.28)
1.482 (37.64)
1.384 (35.15)
.094 (2.39)
.094 (2.39)
24
1.760 (44.70)
1.607 (40.82)
1.511 (38.38)
.094 (2.39)
.094 (2.39)
NOTES:
1. Dimensions are in inches.
2. Metric equivalents are given for information only.
3. Metric equivalents are in parentheses.
4. Unless otherwise specified, tolerances shall be ± .005 (.13 mm) for three place decimals.
5. The method of attachment is optional. The fastener shall not become loose or be damaged when
subjected to a straight axial pull of 5 lb minimum on the chain or rope. The chain or rope shall
rotate freely on the fastener.
6. Coupling assurance indicator shall be provided in accordance with MIL-DTL-83723.
7. These parts are intended for use as protective covers for MIL-DTL-83723, series III, and
MIL-DTL-26500 bayonet coupling connector receptacles.
FIGURE 2. Protective cover, receptacles, bayonet coupling M83723/60-2 - Continued.
4
