MIL-DTL-83723/65F
REQUIREMENTS:
Dimensions and configuration: See figure 1.
This connector mates with MIL-DTL-83723/75 and /77.
For insert arrangements see MIL-STD-1554 and table I.
TABLE I. Insert arrangements requiring reduced diameters for raised
seal barriers on contact cavities as indicated.
Shell size
Insert arrangements
Contact cavities
8
03
1, 2, 3
10
06
1, 2, 3, 4, 5, 6
Contacts: Crimp socket termination in accordance with SAE-AS39029/22.
Connector accessories: SAE-AS85049.
O-ring shall be furnished with connector.
Part or Identifying Number (PIN) example:
M
83723/65
H
22
55
N
Military designation
Specification sheet number
Class
Shell size
Insert arrangement
Polarizing position
Changes from previous issue. Marginal notations are not used in this revision to identify changes with
respect to the previous issue due to the extent of the changes.
Referenced documents. In addition to MIL-DTL-83723, this document references the following:
MIL-DTL-83723/75
MIL-DTL-83723/77
MIL-STD-1554
MS3186
SAE-AS39029/22
SAE-AS85049
6
