MIL-DTL-83723/66B
P
P1
P2
P3
P4
R
R1
Shell
size
8
1.457
1.869
2.018
5.838
1.848
.830
4.585
(37.01)
(47.47)
(51.26)
(148.29)
(46.94)
(21.08)
(116.46)
10
1.457
1.979
2.100
6.528
1.888
.880
5.390
(37.01)
(50.27)
(53.34)
(165.81)
(47.96)
(22.35)
(136.91)
12
1.457
2.124
2.293
7.348
1.928
.950
6.330
(37.01)
(53.95)
(58.24)
(186.64)
(48.97)
(24.13)
(160.78)
14
1.457
2.124
2.353
7.348
1.928
1.010
6.330
(37.01)
(53.95)
(59.77)
(186.64)
(48.97)
(25.65)
(160.78)
16
1.457
2.229
2.502
8.068
2.028
1.070
6.710
(37.01)
(56.62)
(63.55)
(204.93)
(51.51)
(27.18)
(170.43)
18
1.457
2.474
2.614
8.068
2.028
1.130
6.710
(37.01)
(62.84)
(66.40)
(204.93)
(51.51)
(28.70)
(170.43)
20
1.457
2.604
2.739
9.068
2.148
1.190
7.740
(37.01)
(66.14)
(69.57)
(230.33)
(54.56)
(30.23)
(196.60)
22
1.457
2.729
2.864
9.068
2.148
1.260
7.740
(37.01)
(69.32)
(72.75)
(230.33)
(54.56)
(32.00)
(196.60)
24
1.457
2.854
2.989
9.068
2.228
1.320
8.030
(37.01)
(72.49)
(75.92)
(230.33)
(56.59)
(33.53)
(203.96)
FIGURE 2. Plug and backshell assembly, dimensions and configurations.
