MIL-DTL-83723/67B
Shell
A
B
C
D
E
F
G
H
size
dia
dia
dia
dia
dia
thread
dia
dia
8
.500-20
.704
.290
.470
.370
.305
.437
.294
UNF-2A
(17.88)
(7.37)
(11.94)
(9.40)
(7.75)
(11.10)
(7.47)
.625-24
10
.829
.388
.600
.497
.405
.572
.428
UNEF-2A
(21.06)
(9.86)
(15.24)
(12.62)
(10.29)
(14.53)
(10.87)
12
.750-20
1.016
.558
.724
.613
.531
.687
.598
UNEF-2A
(25.81)
(14.17)
(18.39)
(15.57)
(13.49)
(17.45)
(15.19)
14
.875-20
1.079
.627
.849
.738
.665
.812
.667
UNEF-2A
(27.41)
(15.93)
(21.56)
(18.75)
(16.89)
(20.62)
(16.94)
16
1.000-20
1.204
.772
.974
.863
.790
.937
.794
UNEF-2A
(30.58)
(19.61)
(24.74)
(21.92)
(20.07)
(23.80)
(20.17)
18
1.0625-18
1.345
.860
1.030
.919
.869
.992
.900
UNEF-2A
(34.16)
(21.84)
(26.16)
(23.34)
(22.07)
(25.20)
(22.86)
20
1.1875-18
1.470
.985
1.154
1.044
.994
1.117
1.025
UNEF-2A
(37.34)
(25.02)
(29.31)
(26.52)
(25.25)
(28.37)
(26.04)
22
1.3125-18
1.595
1.110
1.279
1.169
1.119
1.242
1.150
UNEF-2A
(40.51)
(28.19)
(32.49)
(29.69)
(28.42)
(31.55)
(29.21)
24
1.4375-18
1.720
1.235
1.404
1.294
1.244
1.367
1.275
(43.69)
(31.37)
(35.66)
(32.87)
(31.60)
(34.72)
(32.39)
UNEF-2A
FIGURE 1. Dimensions and configurations - Continued.
2
