MIL-DTL-83723/68B
P
P1
P2
P3
P4
R
R1
Shell
size
1.457
1.869
2.018
5.838
1.848
.830
4.585
8
(37.01)
(47.47)
(51.26)
(148.29)
(46.94)
(21.08)
(116.46)
1.457
1.979
2.100
6.528
1.888
.880
5.390
10
(37.01)
(50.27)
(53.34)
(165.81)
(47.96)
(22.35)
(136.91)
1.457
2.124
2.293
7.348
1.928
.950
6.330
12
(37.01)
(53.95)
(58.24)
(186.64)
(48.97)
(24.13)
(160.78)
1.457
2.124
2.353
7.348
1.928
1.010
6.330
14
(37.01)
(53.95)
(59.77)
(186.64)
(48.97)
(25.65)
(160.78)
1.457
2.229
2.502
8.068
2.028
1.070
6.710
16
(37.01)
(56.62)
(63.55)
(204.93)
(51.51)
(27.18)
(170.43)
1.457
2.474
2.614
8.068
2.028
1.130
6.710
18
(37.01)
(62.84)
(66.40)
(204.93)
(51.51)
(28.70)
(170.43)
1.457
2.604
2.739
9.068
2.148
1.190
7.740
20
(37.01)
(66.14)
(69.57)
(230.33)
(54.56)
(30.23)
(196.60)
1.457
2.729
2.864
9.068
2.148
1.260
7.740
22
(37.01)
(69.32)
(72.75)
(230.33)
(54.56)
(32.00)
(196.60)
1.457
2.854
2.989
9.068
2.228
1.320
8.030
24
(37.01)
(72.49)
(75.92)
(230.33)
(56.59)
(33.53)
(203.96)
FIGURE 2. Plug and backshell assembly, dimensions and configurations.
5
