MIL-DTL-83723/69B
P
P1
P2
P3
P4
R
R1
Shell
size
1.457
1.869
2.018
5.838
1.848
.830
4.585
8
(37.01)
(47.47)
(51.26)
(148.29)
(46.94)
(21.08)
(116.46)
1.457
1.979
2.100
6.528
1.888
.880
5.390
10
(37.01)
(50.27)
(53.34)
(165.81)
(47.96)
(22.35)
(136.91)
2.124
2.293
7.348
1.928
.950
6.330
1.457
12
(37.01)
(53.95)
(58.24)
(186.64)
(48.97)
(24.13)
(160.78)
1.457
2.124
2.353
7.348
1.928
1.010
6.330
14
(37.01)
(53.95)
(59.77)
(186.64)
(48.97)
(25.65)
(160.78)
2.229
2.502
8.068
2.028
1.070
6.710
1.457
16
(37.01)
(56.62)
(63.55)
(204.93)
(51.51)
(27.18)
(170.43)
1.457
2.474
2.614
8.068
2.028
1.130
6.710
18
(37.01)
(62.84)
(66.40)
(204.93)
(51.51)
(28.70)
(170.43)
1.457
2.604
2.739
9.068
2.148
1.190
7.740
20
(37.01)
(66.14)
(69.57)
(230.33)
(54.56)
(30.23)
(196.60)
1.457
2.729
2.864
9.068
2.148
1.260
7.740
22
(37.01)
(69.32)
(72.75)
(230.33)
(54.56)
(32.00)
(196.60)
2.854
2.989
9.068
2.228
1.320
8.030
1.457
24
(37.01)
(72.49)
(75.92)
(230.33)
(56.59)
(33.53)
(203.96)
FIGURE 2. Plug and backshell assembly, dimensions and configuration.
